The laminating press has an adjustable clamping height easily adjusted by means of a hand wheel. The adjusting interval is 100 mm. The upper clamping beam can be fine adjusted to ensure that it is absolutely parallel to the lower clamping beam.
The clamping pressure is made by means of a pressure hose at the bottom of the press - max. pressure approx. 10 kg/cm². The side straightening is achieved by means of strong side clamps equipped with spindles and hand wheels.
Clamping sizes:
Length: 3600 mm;
Height: 1220 mm;
Width: 120 mm.
Possible variant with pressing on one side.
Construction time: ~ 2 weeks.

The laminating press has an adjustable clamping height easily adjusted by means of a hand wheel. The adjusting interval is 100 mm. The upper clamping beam can be fine adjusted to ensure that it is absolutely parallel to the lower clamping beam.
The clamping pressure is made by means of a pressure hose at the bottom of the press - max. pressure approx. 10 kg/cm². The side straightening is achieved by means of strong side clamps equipped with spindles and hand wheels.
Clamping sizes:
Length: 3600 mm;
Height: 1220 mm;
Width: 120 mm.
Possible variant with pressing on one side.
Construction time: ~ 2 weeks.
